型号 | 流量Q | 转速 r/min | 排出压力 Mpa | 必需汽蚀余量 m | 效率η% | 电动机 | |
m³/h | 频率Hz | 功率KW | |||||
YCB0.6-0.6 | 0.6 | 910 | 0.6 | 5.5 | 32 | 50 | 0.75 |
1.0 | 1390 | 50 | 0.75 | ||||
0.7 | 1130 | 60 | 0.75 | ||||
1.2 | 1710 | 60 | 0.75 | ||||
YCB0.6-1.6 | 0.6 | 910 | 1.6 | 7.0 | 70 | 50 | 1.1 |
1.0 | 1400 | 50 | 1.5 | ||||
0.7 | 1130 | 60 | 1.1 | ||||
1.2 | 1710 | 60 | 1.1 | ||||
YCB1.6-0.6 | 1.6 | 910 | 0.6 | 5.5 | 42 | 50 | 0.75 |
2.5 | 1400 | 50 | 1.1 | ||||
1.9 | 1130 | 60 | 1.1 | ||||
3.0 | 1710 | 60 | 1.5 | ||||
YCB1.6-1.6 | 1.6 | 940 | 1.6 | 7.0 | 71 | 50 | 2.2 |
2.5 | 1440 | 50 | 4 | ||||
1.9 | 1150 | 60 | 2.2 | ||||
3.0 | 1750 | 60 | 4 | ||||
YCB3.3-0.6 | 3.3 | 940 | 0.6 | 5.0 | 60 | 50 | 1.5 |
5.0 | 1420 | 50 | 2.2 | ||||
4.0 | 1150 | 60 | 1.5 | ||||
6.0 | 1730 | 60 | 2.2 | ||||
YCB3.3-1.6 | 3.3 | 960 | 1.6 | 7.0 | 72 | 50 | 5.5 |
5.0 | 1440 | 50 | 7.5 | ||||
4.0 | 1170 | 60 | 4 | ||||
6.0 | 1750 | 60 | 7.5 | ||||
YCB4-0.6 | 4.0 | 940 | 0.6 | 5.0 | 60 | 50 | 1.5 |
6.0 | 1420 | 50 | 2.2 | ||||
4.8 | 1150 | 60 | 2.2 | ||||
7.2 | 1730 | 60 | 3 | ||||
YCB4-1.6 | 4.0 | 960 | 1.6 | 7.0 | 72 | 50 | 5.5 |
6.0 | 1440 | 50 | 7.5 | ||||
4.8 | 1170 | 60 | 5.5 | ||||
7.2 | 1750 | 60 | 7.5 | ||||
YCB8-0.6 | 8.0 | 960 | 0.6 | 5.0 | 61 | 50 | 3 |
12.0 | 1440 | 50 | 5.5 | ||||
9.6 | 1170 | 60 | 4 | ||||
14.4 | 1750 | 60 | 5.5 | ||||
YCB8-1.6 | 8.0 | 970 | 1.6 | 7.0 | 75 | 50 | 11 |
12.0 | 1460 | 50 | 15 | ||||
9.6 | 1170 | 60 | 11 | ||||
14.4 | 1760 | 60 | 15 | ||||
YCB10-0.6 | 10.0 | 960 | 0.6 | 5.0 | 62 | 50 | 4 |
15.0 | 1440 | 50 | 5.5 | ||||
12.0 | 1170 | 60 | 5.5 | ||||
18.0 | 1750 | 60 | 7.5 | ||||
YCB10-1.6 | 10.0 | 970 | 1.6 | 7.0 | 76 | 50 | 11 |
15.0 | 1470 | 50 | 15 | ||||
12.0 | 1170 | 60 | 11 | ||||
18.0 | 1770 | 60 | 18.5 | ||||
YCB20-0.6 | 20.0 | 970 | 0.6 | 5.0 | 68 | 50 | 7.5 |
24.0 | 1170 | 60 | 7.5 | ||||
YCB25-0.6 | 25.0 | 970 | 0.6 | 5.5 | 69 | 50 | 11 |
30.0 | 1170 | 60 | 11 | ||||
YCB30-0.6 | 30.0 | 970 | 0.6 | 5.5 | 70 | 50 | 11 |
36.0 | 1170 | 60 | 11 | ||||
YCB40-0.6 | 40.0 | 970 | 0.6 | 5.5 | 72 | 50 | 15 |
48.0 | 1180 | 60 | 15 | ||||
YCB50-0.6 | 50.0 | 970 | 0.6 | 5.5 | 72 | 50 | 22 |
60.0 | 1180 | 60 | 22 | ||||
